Structure | |
Description | Color coating fiber、Strength member、 Jacket. |
Fiber | SM: G652D、 G655、G657 or other single-mode optical fibers. MM: A1a、A1b or other multi-mode fibers. |
Tight-buffer | Tight-buffered Φ0.6mm、Φ0.7mm、Φ0.9mm. |
Strength Member | Aramid yarn or other high strength yarn. |
Jacket |
Materials: Flame -retardant polyvinyl chloride (PVC),low - smoke halogen - free flame -retardant polyolefin (LSZH), flame- retardant polyethylene (ZRPE ) or other materials. Color : Color as specified by standard or other color. |
Features | |
Application |
Used as pigtails and patch cords. Used in optical communication equipment rooms. Optical connection of Optical Distribution frame. Optical connection for optical instruments and equipment. |
Characteristic |
Good mechanical and environmental performance. Flameretardant(or non--flame retarding)characteristic meets the requirements of relevant standards. Mechanical and physical properties of jacket meet the requirements of relevant standards. Soft,flexible, easy splice,and with big capacity data transmission. |
Temperature | -20℃~+60℃ |
Parameter | ||||||||
Fiber Count |
Cable Dimension (mm) |
Cable Wight (kg) |
Tensile(N) Long Term |
Short Term |
Crush(N/10cm) Long Term |
Short Term |
Bending Radius(mm) Static |
Dynamic |
1 | 1.6 | 2.7 | 40 | 80 | 100 | 500 | 10D | 20D |
1 | 1.8 | 3.0 | 40 | 80 | 100 | 500 | 10D | 20D |
1 | 2.0 | 3.5 | 60 | 100 | 100 | 500 | 10D | 20D |
1 | 2.8 | 6.5 | 80 | 150 | 100 | 500 | 10D | 20D |
2 | 3.0 | 7.0 | 80 | 150 | 100 | 500 | 10D | 20D |
Options
● Cable Dimension: The nominal cable dimension,or other customized dimension;
● Delivery Length: 1.0km or 2.0km,or other customized length;
● Other requirements: Other customized special request.
