| Tube to connector： | HDPE | Working with Fluid： | Air with blowing system |
| Pull test： | 700N | Working Pressure： | 20 bar |
| MAX Pressure： | 28 bar | Userful life： | 25 years |
| Tube assembly： | No tooling required | Water ingress test： | 0.5 bar during 168 hours |
| Working temperature： | -45℃/+50℃ | Transport and storage temperature: | -10℃/+50℃ |
| Installation temperature: | -10℃/+50℃ | Recommended blowing temperature: | -15℃/+35℃ |
| Outdoor exposure limit @Cetral Europe: | 12 months | Protection class: | IP68 |
| High pressure resistance(safety): | ＞50bar | According to Standards: | CEI EN 50411-2-8,EN 50411-2-5 |
As a famous China Micro Duct Connector Factory and Wholesale Micro Duct Connector Suppliers,Ningbo GMF Telecom Technology Co.,Ltd. have over.200 employees. as an ISo9001:2015 and Iso 14001:2004 certificated company, we focus on high quality products, timely service and customer satisfaction to make gmf stand out among the suppliers.Our main products include patch cord, PLC splitter, distribution box, patch panel, ODF, closures, Micro Duct Connector Online.
