Structure | |
Description | Loose tube made of color coating fibers and filled with waterproof compounds.Loose tube stranded around the strength member which in the central of cable into cable core, a layer of water-blockingtape is longitudinall wrapped around the cable core. After corrugated Steel longitudinal wrapped,A layer of outer Jacket extruded with the self-supporting Strength member. |
Fiber | SM: G652D、 G655、G657 or other single-mode optical fibers. MM: A1a、A1b or other multi-mode fibers. |
Jacket |
Materials-polyethylene(PE).low smoke halogen-free flame retardant polyolefin (LSZH).flame-retardant polyetihylene(,ZRPE) or other materials. Color. black or other colors. |
Features | |
Application |
Suitable for self-supporting aeriail |
Characteristic |
Good mechanical and environmental performance. High strength loose tube that is hydrolysis resistant . Strong tensile performance, adapting to all kinds of bad weather. Easy construction and low installation cost. |
Temperature | -40℃~+70℃ |
Parameter | ||||||||
Fiber Count |
Cable Dimension (mm) |
Cable Wight (kg) |
Tensile(N) Long Term |
Short Term |
Crush(N/10cm) Long Term |
Short Term |
Bending Radius(mm) Static |
Dynamic |
1-72 | 4.7+11.5 | 164.0 | 600 | 1500 | 300 | 1000 | 10D | 20D |
73-96 | 5.5+12.5 | 195.0 | 1000 | 3000 | 1000 | 3000 | 10D | 20D |
Options
● Cable Dimension: The nominal cable dimension,or other customized dimension;
● Delivery Length: 1.0km or 2.0km,or other customized length;
● Other requirements: Other customized special request.
As a famous China Outdoor Optical Fiber CalbeFlat Outdoor Cable Factory and Wholesale Outdoor Optical Fiber CalbeFlat Outdoor Cable Suppliers,Ningbo GMF Telecom Technology Co.,Ltd. have over.200 employees. as an ISo9001:2015 and Iso 14001:2004 certificated company, we focus on high quality products, timely service and customer satisfaction to make gmf stand out among the suppliers.Our main products include patch cord, PLC splitter, distribution box, patch panel, ODF, closures, Outdoor Optical Fiber CalbeFlat Outdoor Cable Online.
